AmpC_trig.pdf Manual

AmpC_trig is a combination of a softstart circuit, which limits inrush current to about 7A and mute control for Ground Sound amplifier modules. AmpC_trig will control our amplifier modules PA1CC, PA3CC, PA6CC and PA12CC direct. The board featues an option for power ON LED indication. AmpC_trig will require no idle power when not running as AmpC_trig has a 12Vdc remote trig relay input for power ON = green solution.

• Supply voltage: 230-240V AC
• Softstart circuit
• Mute control
• Remote 12V trigger power ON
• 2,5mm DC-plug connector
• Power On LED output option
• Controlles PA1CC, PA3CC, PA6CC and PA12CC direct
• IEC mains power inlet
• Weight: app. 120g
• Overall dimensions: 70mm x 110mm x 32mm
